Multilayer Flexible Medical PCB Assembly HDI Board 1.6mm Thickness
Multilayer Flexible Multilayer Flexible Pcb Assembly Flexible Circuit B Pcb Assembly Flexible Circuit Board
PCBA Capability
| SMT Lines | 13 Lines |
| Capacity | 8 Million Placements Per Day |
| Max Board Size | 680*550mm Smallest:0.25"*0.25" |
| Min Components size | 0201-54 sq.mm (0.084 sq.inch),Long Connector,CSP,BGA,QFP |
| Speed | 0.15sec/chip, 0.7sec/QFP |
| Wave-Solder | Max.PCB Width:450mm |
| Min.PCB Width:unlimited |
| Components Height:Top 120mm/Bot 15mm |
| Sweat-Solder | Metal Types:Part,Whole,Inlay,Side-step |
| Metal Material:Copper,Aluminum |
| Surface Finish:Plating Au,Plating Silver, Plating Sn |
| Air Bladder Rate: less than 20% |
| Press-fit | Press Range:0-50KN |
| Max.PCB Size:800*600mm |
| Assembly Types | SMT and Thru-hole |
| Solder Type | Water Soluble Solder Paste, Leaded, and Lead-Free |
| File Formats | Bill of Materials, Gerber Files, Pick-N-Place Files(XYRS) |
| Type of Service | Turn-Key, Partial Turn-Kye, or Consignment |
| Component Packaging | Cut Tape, Tube Reels Loose, Parts |
| Turn Time | 1-15days |
| Testing | XRAY Inspection, AOI Testing ICT, Flying Probe, Burn-in, Function Test |
1, Gerber files and BOM provided by the customer
2, Fine-pitch component and BGA placement
3, A good soldering workmanship and reliable quality
4, Flexible production capacity for high-mix model and low to medium order
5, Authorized components source, comprehensive supplier network support
Our capacity and service:
1. PCB fabrication from 1-32 layers. (single side, double side, multi-layer, HDI board, bury& blind holes board etc)
2. Material procurement and management
3. Quick-turn PCBA Prototype and NPI (new product introduction)
4. PCBA and through-hole assembly
5. Complete Unit assembly (Box building includes the plastic, screen, metal enclosure, membrane, coils, wire harness, etc.)
6. Small volume is accepted and High-mix models solutions
7. AOI, In-circuit test, BGA placement, Function testing
8. Engineering support including end of life and obsolete component replacement and design support for circuit, metal,plastic casing, and packaging
